Description

• • MODEL SPECIFICATION



    PUMP	INLET/OUTLET	HP	FLOW	HEAD	PRESSURE TANK
    					24L	35L	60L	100L
    ORG S1HS 2.30	25*25	0.5	2000	21	√	√
    ORG S1HS 2.40	25*25	0.75	2000	28	√	√	√
    ORG S1HS 2.60	25*25	1	2000	42	√	√	√
    ORG S1HS 4.40	35*25	1	4000	30	√	√	√	√
    ORG S1HS 4.50	35*25	1.33	4000	38	√	√	√	√
    ORG S1HS 4.60	35*25	1.5	4000	45	√	√	√	√
    ORG S1HS 8.30	40*32	2.5	8000	36		√	√	√
    ORG S1HS 8.40	40*32	3	8000	48		√	√	√
    ORG S1HS 12.40	40*40	3	12000	39			√	√



UNIQUE FEATURES:

• Elegant Design
• SS 304 5 way connector with inbuilt NRV
• Easy To Install and ready to use
• Silent Running
• Low Maintenance
• Adjustable pressure setting For pump start/stop
• Standard Glycerine Based Pressure Gauge
• Pressure Tank Capacity 8L TO 100L
