ORG Water Softener 100R
- Smart Regeneration: Automatically regenerates when output drops to zero.
- User-Friendly Display: LCD with 72-hour battery backup for convenience.
- High-Performance Design: Handles 2000-3500 LPH with ease.
- Durable Build: High-intensity FRP resin tank and SS stand.
- Efficient Operation: Displays remaining soft water before regeneration.
Description
The ORG Water Softener 100R is a cutting-edge solution designed to address the challenges of hard water effectively. Built with advanced features and robust construction, it offers unmatched performance for both residential and commercial use.
At the core of the system is a high-intensity FRP 1354 resin vessel, ensuring durability and long-lasting efficiency. With a maximum flow rate of 2000 to 3500 litres per hour, it caters to the needs of medium to large-scale water-softening applications. Its 1-inch inlet and outlet size facilitate smooth and efficient water flow, while the working temperature range of 5°C to 50°C and pressure limit of 0.15 – 0.6 Mpa make it adaptable to varying conditions.
The softener’s smart regeneration system activates immediately when the output volume drops to zero, ensuring a consistent supply of soft water without manual intervention. The LCD with a 72-hour battery backup enhances convenience by showing the remaining soft water output before regeneration, helping users plan their water usage efficiently.
Equipped with a brine tank of 100 litres and requiring 12 kg of salt for regeneration, the system is designed for hassle-free maintenance. Its brine valve assembly with a float valve ensures precision during the regeneration process. Additionally, the SS stand provides a sturdy base for installation, while compatibility with Danfoss LP requirements for the BFT MPV model adds to its reliability.
Ideal for homes, businesses, and industrial settings, the ORG Water Softener 100R is a trusted solution for preventing scale buildup, protecting appliances, and enhancing water quality.
Specifications
| Model | Softener 100R |
| Vessels | FRP 1354 |
| Max Flow in LPH | 2000 ~ 3500 |
| MPV Model | 63604 /65605/63604 BFT |
| SV Size | 1/2″ |
| Inlet Outlet size | 1″ |
| Working Temperature | 5°C ~ 50°C |
| Working Pressure | 0.15 – 0.6 Mpa |
| OBR @200ppm | 20000 |
| Resin Quantity | 80 Liter |
| Brine Tank | 100 Liter |
| Salt Required For Regeneration | 12Kg |
| Skid/ Stand | SS Stand |
| LP Required For BFT Mpv | Danfos |
Notable Features:
- Efficient Impurity Removal: Eliminates dissolved impurities such as rust, heavy metals, and salts.
- Automatic Regeneration: Seamlessly regenerates without user intervention when output volume drops.
- User-Friendly Operation: Equipped with an LCD with 72-hour battery backup for convenience.
- Durable Build: High-intensity FRP resin tank and sturdy SS stand ensure long-lasting performance.
