Alfaa UltraPool UV Systems for Pools & Spas
Alfaa UltraPool UV systems UP45 to UP850 for swimming pools and spas. Select by circulation flow and connection size. Ask ABHIRO for model and quotation.
Description
Alfaa UltraPool UV System for Swimming Pools & Spas
Alfaa UltraPool UV systems are designed for compatible swimming-pool and spa water-treatment applications. Model selection should be based on the actual circulation flow, hydraulic arrangement, water quality and current manufacturer sizing guidance.
Manufacturer-listed UltraPool models
| Model | Recommended Flow | Maximum Flow | Inlet / Outlet |
|---|---|---|---|
| UP45 | 2.5 m³/hr | 5 m³/hr | 1.5" BSP |
| UP100 | 6 m³/hr | 12 m³/hr | 2" BSP |
| UP150 | 9 m³/hr | 18 m³/hr | 2" BSP |
| UP250 | 15 m³/hr | 25 m³/hr | 2.5" BSP |
| UP500 | 30 m³/hr | 40 m³/hr | 2.5" BSP |
| UP850 | 52 m³/hr | 60 m³/hr | 3" BSP |
UltraPool UV: Buyer Questions
Should I select using recommended or maximum flow?
Use the manufacturer’s recommended duty as the starting point. The maximum flow is a separate limit; confirm the proposed model against actual flow, water quality and required performance.
Where is UltraPool installed?
Alfaa describes connection between the filtration plant and the pool return. Have the pool-system designer confirm the layout, electrical supply, connections and maintenance clearance.
What should I send for a retrofit quotation?
Send pool volume, actual circulation flow, pipe size, existing filtration layout, available installation space and site city. Confirm model availability and installation scope before ordering.
Call ABHIRO: 9943099998. See UltraPool model-selection guidance.
Before selecting a pool UV system
- Confirm actual circulation flow in m³/hr or LPH.
- Confirm pool volume and filtration/circulation arrangement.
- Confirm connection size and available installation space.
- Check current electrical and monitoring requirements for the selected model.
UV is one part of a complete pool-treatment system and does not replace filtration or the other controls required by the pool design.
